型号：IRT/C.10-K-240F/120C

Features Include:

• Sensing Range: -50 to 1200 °F (-45 to 650 °C)

• Field-of-View: 10:1 (6°) approximately

• Minimum Spot Size: 0.8" (20 mm)

• Spectral Response: 6.5 to 14 µ

• Output Impedance: 4 to 8 Kohms approximately

• Cable: Twisted shielded pair of base thermocouple material (J, K, etc.), 3 ft. (.9) m) standard length, Teflon sheathed, rated to 392 ºF (200 ºC) continuous service.

• Dimensions: 3.76" x 1.375" Diameter (96 x 35 mm)

• Weight: 6.5 oz (184 g) with cable

• Housing: Stainless steel, hermetically sealed, exceeds NEMA 4, 4x; IP65, 67, intrinsically safe, cable shield grounded to housing and electrically isolated from signal.

Air Purge

• Built-in; cooling capacity to 400 °F (200 °C) ambient; 3', (0.9 m) polyurethane tubing provided.

• Air purge pressure: 5 psig - 20 psig (for 400 °F (200 °C) ambient).

•
