型号：IRT/C-K-240F/120C

Series Features Include:

• Sensing Range: -50 to 1200 °F (-45 to 650 °C)

• Ambient Temperature Range: 0 to 212 °F (-18 to 100 °C)

• Optimum Range Selections: Eight models per t/c type (see Temperature Selection Guide)

• Field-of-View: 1:1 (60°) approximately

• Minimum Spot Size: 0.3" (8 mm)

• Spectral Response: 6.5 to 14 µ

• Output Impedance: 3 Kohms approximately

• Cable: Twisted shielded pair of base thermocouple material (J, K, etc.), 3 ft. (.9) m) standard length, Teflon sheathed, rated to 392 ºF (200 ºC) continuous service.

• Dimensions: 1.75" x .50" Diameter (44 x 12.7 mm)

• Weight: 1.4 oz (40 g) with cable

• Housing: Stainless steel, hermetically sealed, exceeds NEMA 4, 4x; IP65, 67, intrinsically safe, cable shield grounded to housing and electrically isolated from signal.
